1000cc strong power Selectable 2WD / 4WD / Lock 4WD with Visco-4Lok front Differential / Electronic Fuel Injection / Automatic CVT P/ R/ N/ L/ H
| Loading Info | ||||||||||||
| 40ft HQ Container | 18 Units | |||||||||||
| 20ft HQ Container | 8Units | |||||||||||
| Packing Size | 2320* 1300* 1230mm | |||||||||||
| Gross Weight | 510 KGS | |||||||||||
| Technical Parameter | ||||||||||||
| Engine & Drivetrain | ||||||||||||
| Cooling | Liquid | |||||||||||
| Cylinders Displacement | 976cc | |||||||||||
| Drive System Type | Selectable 2WD / 4WD / Lock 4WD with Visco-4Lok front Differential | |||||||||||
| Engine Type | 4-Stroke V-Twin， SOHC | |||||||||||
| Bore*Stroke | 91x75 | |||||||||||
| MAX.Torgue | 95NM/5500RPM | |||||||||||
| MAX.Horsepower | 92HP/7300RPM | |||||||||||
| Starting system | Electric | |||||||||||
| Transmission | CVT shaft | |||||||||||
| Fuel System/ Battery | Electronic Fuel Injection | |||||||||||
| Transmission/Final Drive | Automatic CVT P/ R/ N/ L/ H | |||||||||||
| Dimensions | ||||||||||||
| Rack Capacity | 75/ 150 LBS | |||||||||||
| Estimated Dry Weight | 1,014 lb (460 kg) | |||||||||||
| Fuel Capacity | 4.8 Gallons | |||||||||||
| Ground Clearance | 13 in. (33 cm) | |||||||||||
| Overall Vehicle Size (L x W x H) | 2450* 1290* 1500mm | |||||||||||
| Packing Size | 2320* 1280* 1230mm | |||||||||||
| Payload Capacity | 740 lb (336 kg) | |||||||||||
| Person Capacity | 2 | |||||||||||
| Wheelbase | 59 in. (1493 mm) | |||||||||||
| Seat Height | 36.75 in. (93.3 cm) | |||||||||||
| Brakes | ||||||||||||
| Front/ Rear Brakes | Dual 260 mm disc brakes with hydraulic twin-piston calipers | |||||||||||
| Parking Brake | Park In-Transmission and Hand Brake | |||||||||||
| Additional Specifications | ||||||||||||
| Front Suspension | Arched double A-arm with front sway bar | |||||||||||
| Instrumentation | Digital Gauge, Speedometer, Odometer, Tripmeter, Tachometer, Coolant Temperature, Volt Meter, Hour Meter, Service Indicator, Clock, Gear Indicator, Fuel Gauge, Hi-Temp Light, Seatbelt Reminder Light, DC Outlet | |||||||||||
| Lighting | White LED Low/ High & Red LED Tail / Brake Lights | |||||||||||
| Rear Suspension | Torsional Trailing arm Independent (TTI) | |||||||||||
| Tires / Wheels | ||||||||||||
| Electronic Power Steering | Standard | |||||||||||
| Front Tires | 28 x 9-14 | |||||||||||
| Rear Tires | 28 x 11-14 | |||||||||||
| Wheels | Cast Aluminum | |||||||||||
| Red ,Blue ,Green ,Orange ,Yellow ,white ,Black ,Grey | ||||||||||||
