Engine Type:Single,4 stroke,air cooling SOHC Max power:4.3kw/5.77 HP(at 3900 r/m) Max Torque: 11.5 N.M(at 2600 r/m) Carburation: carburetor Engine Displacement:160CM3 Bore*stroke: 68*54 mm Clutch tyre:Friction type torque centrifugal clutch Shift pattern:/ Starting system:electric,with hand-pull starter Fuel Type:92# gasoline Fuel Tank capacity:≥1.7 liter
| Engine Type: | Single,4 stroke,air cooling SOHC |
| Max power: | Max power:4.3kw/5.77 HP(at 3900 r/m) |
| Max Torque: | 11.5 N.M(at 2600 r/m) |
| Carburation: | carburetor |
| Engine Displacement: | 160CM3 |
| Bore*stroke: | 68*54 mm |
| Clutch tyre: | Friction type torque centrifugal clutch |
| Starting system: | electric with hand-pull starter |
| Fuel Type: | 92# gasoline |
| Fuel Tank capacity: | ≥1.7 liter |
| Dimension(L*W*H) | 1800*910*720mm |
| Seat height: | 490mm |
| Net weight: | 75kg |
| Front suspension: | independent double a-shape swing arm |
| Max Front Suspension stroke: | 76mm |
| Brake system: | hand operate cable type |
| Brake Type: | Hoop type central brake |
| Master Transmission type: | chain,type 420(pitch 12.7mm),76 section |
| Propeller: | Rubber Track with front driving wheel |
| Track Type: | Rubber,Reinforced |
| Track width: | 256mm |
| Track Length: | 1728mm,27 teeth |
| Climbing Ability: | ≥6° |
| Max Load: | 40KG |
| Max speed: | ≥12km/h(on stardard flat snow surface) |
| Battery type: | 12v 9AH |
