| Loading Infomation | ||||
| 40ft HQ Container | 6Units | |||
| Packing Size | 4000×1800×1290 | |||
| Gross Weight | 1030kg | |||
| Engine & Drivetrain | ||||
| Cooling | Liquid | |||
| Cylinders Displacement | 996.6cc | |||
| Drive System | Shaft, Selectable 4x4, Front Differential Lock | |||
| Compression Ratio | 10.5 : 1 | |||
| Engine Type | V-twin , 4-Stroke , SOHC | |||
| Fuel System/Battery | DELPHI Electronic Fuel Injection | |||
| Max Power | 63kw(81hp)/6500rpm | |||
| Max Torque | 95N.m/5500rpm | |||
| Transmission | CVT L-H-N-R-P | |||
| Starting system | Electric start | |||
| EFI ignition EPA certification | Have | |||
| Dimensions | ||||
| Overall Length×width×Height | 3925 mm ×1900 mm ×2235mm | |||
| Cargo Box Dimensions | 820 mm ×1480mm ×390mm Dump 25° | |||
| Estimated Dry Weight | 968 kg | |||
| Front/Rea Box Capacity | 50kg/200kg | |||
| Fuel Capacity | 30L | |||
| Wheelbase | 2990 mm | |||
| Ground clearance | 350 mm | |||
| Brakes | ||||
| Front/Rear Barkes | 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers | |||
| Additional Spesifications | ||||
| Cargo System | Electric dump bed | |||
| Doors | Metal Half Door | |||
| Lighting | 4 D-series lights | |||
| Mirrors | Rear mirror | |||
| Roof | Metal Roof | |||
| Tires/Wheels | ||||
| Elec t ronic Pow er St eering | Standard | |||
| Front Tires | 29×9-14 | |||
| Rear Tires | 29×11-14 | |||
| Wheels | Cast Aluminum | |||
| St eering | Rack & pinion Steering | |||
| Suspension | ||||
| Front Suspension Rear Suspension | Dual A-arm | |||
| Dual A-arm with Stabilizer Bar | ||||
